20FT 40FT Container 8 Tubes Used CNG Semi Trailer With Good Condition
CNG tank /8/9/10/11 tubes container is a new professional storage and transportation equipment for Compressed Natural Gas(CNG), the features are flexible, convenient, efficient, it is the latest means of mass transportation specialized for compressed natural gas, applies to road transport compressed natural gas (CNG) (does not apply to the transportation of liquefied gases and dissolved gases).
Application
1. For CNG transportation from Mother station/gas reserve to daughter station;
2. For CNG transportation to places where pipeline network hasn't been built;
3. For CNG transportation to places where can't reach existing distribution system etc;
4. For CNG storage at gas stations.
Product Parameter (specification)
|
External dimension (length × width × height) |
12192x2438x1925 mm |
|
Unladen mass |
31000 kg |
|
Rated loading mass |
5742(20ºC)kg |
|
Total mass |
36742 kg |
|
Total volume |
25.52 m3 |
|
Air-tight test |
25 MPa |
|
Filling mouth diameter |
1"NPT |
|
Executive standard of steel cylinder |
Q/1500LXZ 001-2015 |
|
Nominal working pressure |
25 MPa |
|
Environment temperature |
-50~65 ºC |
|
Filling medium |
Compressed natural gas |
|
Single nominal volume |
2.32 m3 |
|
Filling mass |
522(20ºC)Kg |
|
Seamless steel cylinder mass |
2435 Kg |
|
Hydraulic test |
37.5 Mpa |
|
Air-tight test |
25 Mpa |
|
Boundary dimension (diameter × length) |
Φ559x10985 |
|
Cylinder body material |
4130X |
Specific details
Features of benhong high-pressure gas cylinder:
1. Heat-spinning technology;
2. Walking beam continuous heat treatment;
3. Large-size structure and fewer valves, tubes and joints;
4. Concise design, less maintenance on site;
5. Lower weight of design;
6. Additional gas-filling devices.
The unpowered gas station technology, in the parent station, consumes 690 degrees of electricity for every 10000 cubic meters of CNG to 25MPa pressurized (more than 80 degrees of electricity is consumed by about 2000 cubic meters of 20MPa to 25MPa pressurized). It is transported to the sub station by 25MPa cylinder Trailer. With the patented technology of "multi cylinder alternating circulation", the secondary pressurization equipment is no longer needed, and the inflated cylinder can be filled to 20MPa. No noise and pollution emissions, real energy conservation and environmental protection. Compared with the same conditions, for every 10000 cubic meters of CNG sold, the power consumption of secondary pressurization is 1160-690 = 470 degrees. The energy consumption of different compressor models is slightly different.
